Fabtek Stainless Steel 45 Gallon Tank Washdown Condensate Units In Stock

The Washdown Duty Stainless Steel Condensate Units include a NEMA 4 Float Switch (Simplex) or a NEMA 4 Mechanical Alternator (Duplex). The Float Switches/Alternators are Epoxy Coated & Gasketed for Watertight Service. The tank connection bushings for the switches are of Stainless Steel Construction. Stainless Steel Seal Vent Lines and fittings are provided. Washdown Duty Motors are available with a USDA approved White Epoxy Finish or with all 300 Series Stainless Steel Exterior Components both of which meet IP55 enclosure protection requirements.



For more severe environments, Premium Stainless Steel Motors are Available with IEEE 841 Severe Duty Features and IP56 Enclosure Protection. Clean Room compliant WashDown motors with Epoxy Resin Winding Encapsulation, Pre-Lubricated Double Sealed Bearings and Output Shaft Seal Bearing Isolators can be provided as well. Control Panels are available for Single Phase** or Three Phase Power for 60Hz 115/208/230/460/575VAC voltage. Panels are available in NEMA 4 Steel, NEMA 4X Fiberglass, NEMA 4X Stainless Steel and Clean Room Compliant NEMA 4X “Washguard” Stainless Steel Enclosures. Panels are mounted to receivers using SS Brackets and wired to pumps and switches using liquid-tite conduit. Panels can also be shipped loose for remote mounting. *5 year warranty excludes the mechanical seal. Pump Motors carry their manufacturer’s warranty only. **Control Panels are not required for Single Phase Power unless High Level Alarm Circuit and Annunciation are desired. Single Phase Pumps will run Directly from Pilot Signal from NEMA 4 Float Switch/Alternator

Item Name: Simplex Unit
Manufacturer:
Fabtek
Description:

Stainless Steel Condensate Return Unit

  • 304 Stainless Steel Receivers with 20 Year Warranty due to corrosion.
  • 304 SS Vertical Flange mounted centrifugal pumps.
  • Heavy Duty SS Sight Gauge Valve Assembly
  • Nema 1 Float Switch ( Simplex )
  • Nema 1 Mechanical Alternator (Duplex)
  • TEFC Motor Enclosures
  • 1,000 - 150,000 Sq. Ft. EDR
  • 2,500 - 27,500  PPH
  • Floor Mounted units are rated for 200º F condensate and up to 210ºF
Shipping Time: 1-3 Business Day
Express ship options available
45 Gallon Simplex 30 Gpm Model Single & Three Phase
Part # Tank Size EDR (Sq. Ft.) GPM PSIG HP Unit
45150505C4BC1S 45 gal 30000 30 15 1/2 Simplex 1 Phase Add to RFQ
45150505C4BC3S 45 gal 30000 30 15 1/2 Simplex 3 Phase Add to RFQ
45200505C4BC1S 45 gal 30000 30 20 1/2 Simplex 1 Phase Add to RFQ
45200505C4BC3S 45 gal 30000 30 20 1/2 Simplex 3 Phase Add to RFQ
45250101C5CD1S 45 gal 30000 30 25 1 Simplex 1 Phase Add to RFQ
45250101C5CD3S 45 gal 30000 30 25 1 Simplex 3 Phase Add to RFQ
45301515C5BC1S 45 gal 30000 30 30 1-1/2 Simplex 1 Phase Add to RFQ
45301515C5BC3S 45 gal 30000 30 30 1-1/2 Simplex 3 Phase Add to RFQ
45400202C6BC1S 45 gal 30000 30 40 2 Simplex 1 Phase Add to RFQ
45400202C6BC3S 45 gal 30000 30 40 2 Simplex 3 Phase Add to RFQ
45503030C6CD3S 45 gal 30000 30 50 3 Simplex 3 Phase Add to RFQ
45 Gallon Simplex 37.5 Gpm Model Single & Three Phase
Part # Tank Size EDR (Sq. Ft.) GPM PSIG HP Unit
45150505C4BC1S 45 gal 37500 37.5 15 1/2 Simplex 1 Phase Add to RFQ
45150505C4BC3S 45 gal 37500 37.5 15 1/2 Simplex 3 Phase Add to RFQ
45200707C4CD1S 45 gal 37500 37.5 20 3/4 Simplex 1 Phase Add to RFQ
45200707C4CD3S 45 gal 37500 37.5 20 3/4 Simplex 3 Phase Add to RFQ
45251515C5BC1S 45 gal 37500 37.5 25 1-1/2 Simplex 1 Phase Add to RFQ
45251515C5BC3S 45 gal 37500 37.5 25 1-1/2 Simplex 3 Phase Add to RFQ
45301515C5CD1S 45 gal 37500 37.5 30 1-1/2 Simplex 1 Phase Add to RFQ
45301515C5CD3S 45 gal 37500 37.5 30 1-1/2 Simplex 3 Phase Add to RFQ
45403030C6CD3S 45 gal 37500 37.5 40 3 Simplex 3 Phase Add to RFQ
45503030C6CD3S 45 gal 37500 37.5 50 3 Simplex 3 Phase Add to RFQ
45 Gallon Simplex 45 Gpm Model Single & Three Phase
Part # Tank Size EDR (Sq. Ft.) GPM PSIG HP Unit
45150505C4DE1S 45 gal 45000 45 15 1/2 Simplex 1 Phase Add to RFQ
45150505C4DE3S 45 gal 45000 45 15 1/2 Simplex 3 Phase Add to RFQ
45200707C4CD1S 45 gal 45000 45 20 3/4 Simplex 1 Phase Add to RFQ
45200707C4CD3S 45 gal 45000 45 20 3/4 Simplex 3 Phase Add to RFQ
45251515C5CD1S 45 gal 45000 45 25 1-1/2 Simplex 1 Phase Add to RFQ
45251515C5CD3S 45 gal 45000 45 25 1-1/2 Simplex 3 Phase Add to RFQ
45302020C5DE1S 45 gal 45000 45 30 2 Simplex 1 Phase Add to RFQ
45302020C5DE3S 45 gal 45000 45 30 2 Simplex 3 Phase Add to RFQ
45403030C6CD3S 45 gal 45000 45 40 3 Simplex 3 Phase Add to RFQ
45503030C6BC3S 45 gal 45000 45 50 3 Simplex 3 Phase Add to RFQ
Item Name: Duplex Unit
Manufacturer:
Fabtek
Description:

Stainless Steel Condensate Return Unit

  • 304 Stainless Steel Receivers with 20 Year Warranty due to corrosion.
  • 304 SS Vertical Flange mounted centrifugal pumps.
  • Heavy Duty SS Sight Gauge Valve Assembly
  • Nema 1 Float Switch ( Simplex )
  • Nema 1 Mechanical Alternator (Duplex)
  • TEFC Motor Enclosures
  • 1,000 - 150,000 Sq. Ft. EDR
  • 2,500 - 27,500  PPH
  • Floor Mounted units are rated for 200º F condensate and up to 210ºF
Shipping Time: 1-3 Business Day
Express ship options available
45 Gallon Duplex 30 Gpm Model Single & Three Phase
Part # Tank Size EDR (Sq. Ft.) GPM PSIG HP Unit
45150505C4BC1D 45 gal 30000 30 15 1/2 Duplex 1 Phase Add to RFQ
45150505C4BC3D 45 gal 30000 30 15 1/2 Duplex 3 Phase Add to RFQ
45200505C4BC1D 45 gal 30000 30 20 1/2 Duplex 1 Phase Add to RFQ
45200505C4BC3D 45 gal 30000 30 20 1/2 Duplex 3 Phase Add to RFQ
45250101C5CD1D 45 gal 30000 30 25 1 Duplex 1 Phase Add to RFQ
45250101C5CD3D 45 gal 30000 30 25 1 Duplex 3 Phase Add to RFQ
45301515C5BC1D 45 gal 30000 30 30 1-1/2 Duplex 1 Phase Add to RFQ
45301515C5BC3D 45 gal 30000 30 30 1-1/2 Duplex 3 Phase Add to RFQ
45400202C6BC1D 45 gal 30000 30 40 2 Duplex 1 Phase Add to RFQ
45400202C6BC3D 45 gal 30000 30 40 2 Duplex 3 Phase Add to RFQ
45503030C6CD3D 45 gal 30000 30 50 3 Duplex 3 Phase Add to RFQ
45 Gallon Duplex 37.5 Gpm Model Single & Three Phase
Part # Tank Size EDR (Sq. Ft.) GPM PSIG HP Unit
45150505C4BC1D 45 gal 37500 37.5 15 1/2 Duplex 1 Phase Add to RFQ
45150505C4BC3D 45 gal 37500 37.5 15 1/2 Duplex 3 Phase Add to RFQ
45200707C4CD1D 45 gal 37500 37.5 20 3/4 Duplex 1 Phase Add to RFQ
45200707C4CD3D 45 gal 37500 37.5 20 3/4 Duplex 3 Phase Add to RFQ
45251515C5BC1D 45 gal 37500 37.5 25 1-1/2 Duplex 1 Phase Add to RFQ
45251515C5BC3D 45 gal 37500 37.5 25 1-1/2 Duplex 3 Phase Add to RFQ
45301515C5CD1D 45 gal 37500 37.5 30 1-1/2 Duplex 1 Phase Add to RFQ
45301515C5CD3D 45 gal 37500 37.5 30 1-1/2 Duplex 3 Phase Add to RFQ
45403030C6CD3D 45 gal 37500 37.5 40 3 Duplex 3 Phase Add to RFQ
45503030C6CD3D 45 gal 37500 37.5 50 3 Duplex 3 Phase Add to RFQ
45 Gallon Duplex 45 Gpm Model Single & Three Phase
Part # Tank Size EDR (Sq. Ft.) GPM PSIG HP Unit
45150505C4DE1D 45 gal 45000 45 15 1/2 Duplex 1 Phase Add to RFQ
45150505C4DE3D 45 gal 45000 45 15 1/2 Duplex 3 Phase Add to RFQ
45200707C4CD1D 45 gal 45000 45 20 3/4 Duplex 1 Phase Add to RFQ
45200707C4CD3D 45 gal 45000 45 20 3/4 Duplex 3 Phase Add to RFQ
45251515C5CD1D 45 gal 45000 45 25 1-1/2 Duplex 1 Phase Add to RFQ
45251515C5CD3D 45 gal 45000 45 25 1-1/2 Duplex 3 Phase Add to RFQ
45302020C5DE1D 45 gal 45000 45 30 2 Duplex 1 Phase Add to RFQ
45302020C5DE3D 45 gal 45000 45 30 2 Duplex 3 Phase Add to RFQ
45403030C6CD3D 45 gal 45000 45 40 3 Duplex 3 Phase Add to RFQ
45503030C6BC3D 45 gal 45000 45 50 3 Duplex 3 Phase Add to RFQ
